MTSX RSS CHANGE/VIEW
68P81074C50 6-69
This screen is used to enter the Subfleets that will use each personality. Once the subfleets are entered, they are
assigned to the Zone/System or Channel/Subfleet selector at the Zone/Summary screen (F4/F8).
If the radio is a secure equipped radio, then strapping fields will be visible, and secure strapping can be set up for
each field. The personality may have up to 16 talkgroups (the number of positions on the rotary switch) indicated
by the numbers 1-16, including an Announcement and/or a Dynamic Regrouping talkgroup.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - ADD SUB FLT (Add Subfleet) allows you to add a Subfleet.
F5 - DELETE SUB FLT (Delete Subfleet) allows you to delete a Subfleet.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
6.2.2.4.1 TRUNKING SUBFLEETS
RSS LOCATION: At the CHANGE/VIEW MENU, press .
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Press F4. The TRUNKING PERSONALITY screen appears.
4. Press F7. The TRUNKING SUBFLEETS screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the UP/DOWN arrow keys to select choice or value.
MOTOROLA Radio Service Software
MTSX Model:
...CHANGE/VIEW:TRUNKING:PERS:SUBFLEET
Enter or Scroll UP/DOWN to Select ID
(in Hex)
Personality ................1
TRUNKING SUBFLEETS
# Subfleet Failsoft F/S Frequency
1 001
F1
HELP
F2
ADD
SUB FLT
F3 F4 F5
DELETE
SUB FLT
F6 F7 F8 F9 F10
EXIT
To Next Page
