CHANGE/VIEW MTSX RSS
6-38 68P81074C50
6.2.2 TRUNKING MENU
RSS LOCATION: At the CHANGE/VIEW MENU, press .
This menu allows you to navigate to the trunking edit screens. The options in these screens pertain only to
trunking radio features.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - TRUNK WIDE OPT (Trunking Radio Wide Options) screens are applicable to all trunking operation,
regardless of system type or signalling type.
F3 - TRUNK SYS (Trunking Systems) is used to change and view trunked system parameters. A trunking
system refers to a specific repeater site, system ID, control channel frequencies, and the connect tone
required to operate on that system.
F4 - TRUNK PERS (Trunking Personality) allows you to change and view the parameters for a trunking
personality. A trunking personality refers to the type of features and options that are used on a trunking
channel or talkgroup. Multiple personalities may use the same system, and multiple talkgroups may also
use the same personality.
F5 - TRUNK ID LIST (Trunking Call List) allows you to edit the list of Trunking Call IDs and the corresponding
names (or alias). This screen is visible only if the radio supports this option.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
MOTOROLA Radio Service Software
MTSX Model:
MENU:CHANGE/VIEW:TRUNKING
Select Function F1 - F10.
TRUNKING MENU
F1 - HELP
F2 - Trunking Radio Wide Options
F3 - Trunking Systems: System ID, Control Channels, etc.
F4 - Trunking Personality: Talk Groups, Emergency options, etc.
F5 - Trunking Call List Data
F6 -
F7 -
F8 -
F9 -
F10 - EXIT, Return to Change/View Menu
F1
HELP
F2
TRUNK
WIDE OPT
F3
TRUNK
SYS
F4
TRUNK
PERS
F5
TRUNK ID
LIST
F6 F7 F8 F9 F10
EXIT
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Select the desired function key (F1 - F10).
