3-28 68P81074C50
TUTORIAL MTSX RSS
3.4.7 Clone Additional Radios
Instruction What to Type How to do it/What it Means
Table 3-25. Cloning Additional Radios
Connect cable from RIB to the radio.
Press F5 at the GET/SAVE Menu to clone the
radio. This saves (programs) the source file into
the current radio.
Press F8. The cloning process will check for
compatibility of the two radios automatically. You
will receive an error message if cloning cannot be
performed.
When Step 2 is completed, disconnect the radio.
Repeat Steps 1-3 for remaining radios. If for any
reason the radios cannot be cloned, an error
message will appear. Check all connections or
refer to Appendix A.
1. Connect the next target radio
2. Clone the radio
3. Clone the Radio
4. Disconnect the radio
5. Clone remaining radios
Congratulations! You are now a radio programmer! You now have a foundation for programming more radios.
To retain a good portion of what you've learned so far, please review this material or program another radio within
48 hours.
Instruction What to Type How to do it/What it Means
Table 3-26. Steps to Exit the RSS
Press Esc to back up to MAIN MENU.
Press F10 then F2 to exit to DOS.
1. Go to MAIN MENU menu.
2. Exit to DOS
To Next Page
