3-18 68P81074C50
TUTORIAL MTSX RSS
3.3.9 Steps to Assign Controls
At the Radio Wide Features Configuration Menu, we will assign button and switch functions.
Instruction What to Type How to do it/What it Means
Table 3-16. Steps to Assign Button and Switch Functions
Press F4 at the MAIN MENU to see the
CHANGE/VIEW Menu.
At the CHANGE/VIEW menu, press F3 to see the
Radio Wide Configuration Menu.
Press F3 to see Radio Wide Features
Configuration Menu.
Press F2 to see Radio Wide Button Configuration
Screen. The Orange Button (Conventional
Feature) will be highlighted.
Pressing Tab advances the prompt to the next
field.
Press up/down arrow keys to select Chan/Sub
Select for Conventional and Trunking columns
Press F10 to return to Radio Wide Features
Configuration Menu.
Press F3 to see Radio Wide Switch Configuration
Screen. The Two Position Concentric field
(Conventional Feature) will be highlighted.
Press up/down arrow keys to select Scan for
Position A, and Blank for position B. Repeat
process for Trunking Column.
Pressing Tab advances the prompt to the next
field.
Press up/down arrow keys to select Zone/Sys
Select for all three switch positions. Repeat
process for Trunking Column.
Press F10 twice to see Radio Wide Configuration
menu.
1. Go to CHANGE/VIEW menu
2. Go to Radio-Wide
Configuration Menu
3. Go to Radio Wide Features
Configuration Menu
4. Go to Radio Wide Button
Configuration screen
5. Go to 16 Pos Rotary field
6. Select Chan/Sub Select
7. Exit to Radio Wide Features
Configuration Menu
8. Go to Radio Wide Switch
Configuration screen
9. Select Scan for Position A
Select Blank for Position B
10. Go to Three position Toggle
field
11. Select "Zone/Sys Select" for
Positions A, B, and C
12. Exit to Radio Wide
Configuration Menu
