MTSX RSS CHANGE/VIEW
68P81074C50 6-53
MOTOROLA Radio Service Software
MTSX Model:
...TRUNKING:SYSTEM:CHAN ASSIGN
Enter or Scroll to Select System.
System......................................1
CHANNEL ASSIGNMENT DATA
Rx Channel Ranges - MHz Tx Channel Ranges - MHz
Spacing Spacing
# Status (kHz) Start End Status (kHz) Start End
1 Enable 6.25 136.00000 136.00000 Enable 6.25 136.00000 136.00000
2 Blank Blank
3 Blank Blank
F1
HELP
F2 F3
PREV
SYS
F4
NEXT
SYS
F5 F6
CONTROL
CHANNEL
7 F8 F9 F10
EXIT
6.2.2.2.1 CHANNEL ASSIGNMENT DATA
RSS LOCATION: At the CHANGE/VIEW MENU, press .
This screen is used to enter the Channel Assignment data used for OB. (Other Band Trunking). Three different
frequency splits may be defined for each system.
After the Receive and Transmit ranges are defined, press F6 to enter the Control Channel frequencies.
Caution
This information must match the Central Controller exactly or the system will not work.
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Press F3. The TRUNKING SYSTEM screen appears.
4. Press F6. The CHANNEL ASSIGNMENT DATA screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the up/down arrow keys to select choice or value.
To Next Page
