SERVICE MTSX RSS
4-24 68P81074C50
MOTOROLA Radio Service Software
MTSX Model:
...SECURE RECEIVE DISCRIMINATOR LEVEL
Use UP/DOWN Arrows To Adjust Softpot.
F1
HELP
F2 F3 F4 F5 F6 F7 F8
PROGRAM
VALUE
F9 F10
EXIT
SECURE RECEIVE DISCRIMINATOR LEVEL
Frequency Current Value
403.1500 81 New Softpot Value...............110
0
Min
127
Max
4.2.2.7 SECURE RECEIVE DISCRIMINATOR LEVEL
RSS LOCATION: At the SERVICE MENU, press .
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F8 - PROGRAM VALUE function will program the selected value into the radio.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
New Softpot Value Field Definition
This is the secure receive discriminator level softpot value for this frequency. The status bar shows the
relationship between this setting and the minimum and maximum settings.
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F3. The RECEIVE ALIGNMENT MENU appears.
3. Press F8. The SECURE RECEIVE DISCRIMINATOR LEVEL screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
Refer to your radio service manual for the squelch alignment procedure. This procedure should only be attempted
by qualified service personnel.
Secure receive discriminator level should be checked any time the radio is serviced and must be adjusted
whenever any of the modulation circuitry has been replaced.
