68P81074C50 3-17

MTSX RSS TUTORIAL

Instruction What to Type What it Does or Means

Table 3-14. Steps to Read A Radio's Personality (Codeplug)

Press F3 at the MAIN MENU to get to the

GET/SAVE Menu.

At the GET/SAVE menu, press F2 to execute the

function. You will also see an indication of how

much of the radio codeplug has been read.

1. Go to GET/SAVE menu

2. Get current radio's codeplug

data

Instruction What to Type What it Does or Means

Table 3-15. Steps to Merge/Download TCMS

Press F3 at the MAIN MENU to get to the

GET/SAVE Menu.

At the GET/SAVE menu, press F4 to get TCMS

codeplug update disk file.

The TCMS Path is highlighted. We assumed the

TCMS file was in the appropriate directory, if this

path is not in the highlighted area, type in the

appropriate path name.

Press Esc to exit to MAIN MENU.

1. Go to GET/SAVE menu

2. Go to MERGE FORM

3. Update Data

4. Exit to MAIN MENU

3.3.6 Read Current Radio's Personality (Codeplug)

Before we can program the MTX8000 with some features we must read and access the current radio's

personality (codeplug data).

3.3.8 Program the Radio-Wide Features First

After the MTX8000 radio's codeplug data is read, and the TCMS file is merged, the RSS allows us to access the

CHANGE/VIEW menu. From here we can program the features that are unique to each system or personality

and the ones that are common to all. First we'll program the common (radio-wide) features. Note that some

screens are not accessed, leaving many parameters at factory default values, which are suitable in most cases.

3.3.7 TCMS Merge Process

For this tutorial, we will assume that the TCMS file is in the appropriate directory. Before we can program the

MTX8000 with some features we must merge the TCMS file into the MTX8000 radio. Table 3-15 describes the

TCMS merge process.

ESC
