68P81074C50 3-27
MTSX RSS TUTORIAL
Instruction What to Type How to do it/What it Means
Table 3-24. Steps to Clone Radios
1. Go to GET/SAVE menu.
2. Go to GET ARCHIVE FILE
3. Change the Archive path
4. Type in path name
5. Select desired file
6. Get selected file
7. Return to the GET/SAVE Menu
8. Connect target radio
9. Save source into target radio
10. Clone the Radio
11. Disconnect radio
12. Proceed to Step 1 in next table
for cloning additional radios
(Press Esc to back up to MAIN MENU.) Press F3
at the MAIN MENU to see the GET/SAVE menu.
Press F3 at the GET/SAVE menu to go to GET
ARCHIVE FILE screen. A list of files is displayed
which look like serial numbers that the RSS found
under the archive path name.
Press F2 to highlight the archive path.
This tells the RSS to display the file names found
in this directory. You will see the file named
xxxxxxxx.xxx that you saved in the first tutorial.
Press Tab until the selected file is highlighted.
Press F8 to get the selected (highlighted) file.
Press F10 to return to the GET/SAVE menu.
Assemble the hardware and connect the radio you
want cloned.
Press F5 from GET/SAVE to clone the current
radio's codeplug with the selected source file's
personality.
Press F8. The cloning process will check for
compatibility of the two radios automatically. You
will receive an error message if cloning cannot be
performed. If for any reason the radios cannot be
cloned, an error message will appear. Check all
connections or refer to Appendix A.
When Step 8 is completed, you can disconnect the
radio. In a matter of seconds the second radio
was cloned. Disconnecting the radio should only
be done at the GET/SAVE menu or the MAIN
MENU, or the radio may be left in an inoperable
state.
