MTSX RSS CHANGE/VIEW
68P81074C50 6-19
This screen allows you to edit the radio-wide menu list. Radio models with front display utilize a Menu to simplify
the operation of the radio. This screen is used to customize the radio for the required feature set.
The radio will automatically use either the Conventional or Trunking menu functions as required. If a personality
does not use a specific feature, the radio will not display that menu item for that personality.
The menu items are displayed in the order in which they are placed in the list. Therefore, the first three items will
always be shown when the menu is entered (assuming that personality uses those items).
Use F2 to add and F4 to delete conventional items.
Use F7 to add and F9 to delete trunking items.
WARNING
Do NOT duplicate a function on multiple controls, i.e. a button and a switch, or a button and a
menu, or a switch and a menu. This may cause the radio to malfunction, and can cause operator
confusion.
Function key descriptions and field definitions are on the following page.
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:CONFIG:FEATURES:MENUS
Use UP/DOWN Arrows to Select Choice.
RADIO WIDE MENU ITEM CONFIGURATION
# Conv Item # Conv Item # Trunk Item # Trunk Item
1 ZONE/SYS 1 ZONE/SYS 9 MUTE
2 DIR 2 MUTE
3 MUTE 3 CALL
4 STS
5 MSG
6 RPGM
7 PROG
8 VIEW
F1
HELP
F2
ADD
CNV ITM
F3 F4
DELETE
CNV ITM
F5 F6 F7
ADD
TRK ITM
F8 F9
DELETE
TRK ITM
F10
EXIT
6.2.1.2.3 RADIO WIDE MENU ITEM CONFIGURATION
RSS LOCATION: At the CHANGE/VIEW MENU, press .
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3. Press F3. The RADIO WIDE FEATURES CONFIGURATION MENU appears.
4. Press F4. The RADIO WIDE MENU ITEM CONFIGURATION screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the up/down arrow keys to select choice or value.
