MTSX RSS CHANGE/VIEW
68P81074C50 6-131
A zone is an artificial grouping of channels (or talkgroups) to permit ease of operation. Generally, all members of
a zone will reflect some common characteristic such as geographic location, job function, signalling type, etc.
Each member of a zone is defined by selecting a conventional personality, or a trunking personality and a
talkgroup. An optional name can also be assigned to each member of the zone. Each zone can also be named
on radios equipped with a display The number of characters allotted for the zone name versus the channel
name is defined on the RADIO WIDE DISPLAY OPTIONS screen (F4/F3/F6). Zones and channels can be added
and deleted via the function keys designated at the bottom of the screen.
Zone selection may be via the rotary switch, the toggle switch, or the keypad (if applicable).
Function key descriptions and field definitions are on the following page.
6.2.4 ZONE/TALKGROUP (CHANNEL) ASSIGNMENT
RSS LOCATION : At the CHANGE/VIEW MENU, press .
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F8. The ZONE/TALKGROUP (CHANNEL) ASSIGNMENT screen appears.
3. Press Tab to select the desired field, or press the desired function key (F1 - F10).
4. If a field is selected, press the UP/DOWN arrow keys to select choice or value.
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:ZONE/CHAN
Enter or Scroll to Select Value.
Zone Number .......1 ZONE/TALKGROUP (CHANNEL) ASSIGNMENT
Zone Name...........Z1
Personality Talkgroup
Channel Number Channel Name Type Number Number Strapping
1 CHAN 1 Conv 1
F1
HELP
F2
ADD
ZONE
F3
PREV
ZONE
F4
NEXT
ZONE
F5
DELETE
ZONE
F6
ADD
CHAN
F7
DELETE
CHAN
F8 F9 F10
EXIT
To Next Page
