GETTING STARTED MTSX RSS
2-36 68P81074C50
2.13 SETUP CONFIGURATION
RSS LOCATION: At the MAIN MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CONFIGURATION
SERVICE SOFTWARE CONFIGURATION
F1 - HELP
F2 -
F3 - PC CONFIGURATION, Drives, Paths, Ports, etc.
F4 -
F5 -
F6 -
F7 - SCREEN Color Configuration
F8 -
F9 -
F10 - Exit, Return to Main Menu
F1
HELP
F2 F3
CONFIGURE
PC
F4 F5 F6 F7
SCREEN
COLORS
F8 F9 F10
EXIT
The Setup Computer Configuration screen is accessed by pressing F9 at the MAIN MENU. From this screen, you
may set up the paths for the archive file. You may also setup the serial port (COM 1 or COM 2) that will be used
to communicate with the radio.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F3 - CONFIGURE PC is used to set default disk drive paths for archive files and backup files. It is also used to
select which asynchronous communications port (COM 1 or COM 2) the RIB will be connected to. The radio
service software will automatically determine at what clock speed the computer is operating on. No user-
selectable parameters are required.
F7 - SCREEN COLORS is used to enable the color display option. The standard default configuration for Radio
Service Software is for a monochrome display monitor. However, if the computer is capable of color display
the viewing quality is greatly enhanced. (Refer to your computer’s owner’s manual for a complete
description of path names and asynchronous communication ports.)
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at at time.
To Next Page
