SERVICE MTSX RSS
4-6 68P81074C50
4.2.1.2 TRANSMIT POWER ALIGNMENT
RSS LOCATION: At the SERVICE MENU, press .
Refer to your radio service manual for the transmitter power alignment procedure. This procedure should only be
attempted by qualified service personnel.
The adaptive splatter control feature uses the transmitter power settings for reduced transmit power under strong
received signal conditions to reduce adjacent-channel interference.
Transmitter power is adjusted by first keying the radio via F6, and then by pressing the up/down arrow keys to
increase or decrease power respectively. SHIFT up/down will increase the adjustment speed. A relative Tx power
value (NOT WATTS) will be displayed, but the actual transmitter power output must be determined from your
service monitor.
Function key descriptions and field definitions are on the following page.
TRANSMIT POWER
Current Value New Softpot Value
Frequency
High Pwr Low Pwr High Pwr Low Pwr
806.0125 30 26 30 26
815.0125 42 42 42 42
824.9875 50 50 50 50
851.0125 60 60 60 60
860.0125 70 70 70 70
869.9875 80 80 80 80
Transmitter..........Off
MOTOROLA Radio Service Software
MTSX Model:
...TRANSMIT POWER
Use UP/DOWN Arrows To Adjust Softpot.
F1
HELP
F2 F3 F4 F5 F6
TOGGLE
PTT
F7 F8
PROGRAM
VALUE
F9 F10
EXIT
0
Min
127
Max
F2
F3
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F2. The TRANSMITTER ALIGNMENT MENU appears.
3. Press F3. The TRANSMIT POWER screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
