MOTOROLA Radio Service Software
MTSX Model:
...CONFIG:RADIO OPTIONS:EMERG OPT
Use UP/DOWN Arrows to Select Choice.
RADIO WIDE EMERGENCY OPTIONS
Silent Alarm ........................Enabled
Unmute Option.................Disabled
Channel Delay (sec) ....................02
Man Down Pre-Alert (sec)............10
Man Down Post-Alert (sec)..........10
F1
HELP
F2 F3 F4 F5 F6 F7 F8 F9 F10
EXIT
The Emergency parameters listed on this screen are radio-wide, in that they apply both to conventional and
trunking signaling. Emergency operation must be enabled in the system selected for signalling Type in the
Conventional Personality screen (F4/F6/F3) and/or the Trunking personality screen (F4/F4/F4/F8). In addition,
the Emergency button must be configured from the Radio Wide Button screen (F4/F3/F3/F2).
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3. Press F2. The RADIO WIDE OPTIONS screen appears.
4. Press F7. The RADIO WIDE EMERGENCY OPTIONS screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the up/down arrow keys to select choice or value.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
Fields are defined on the following page.
