MTSX RSS CHANGE/VIEW
68P81074C50 6-39
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - SMRTZN ENV calls up the screen which allows setting of parameters which are related to the SmartZone
operating environment. This function will only be visible when a radio with the SmartZone software option
has been read.
F3 - VOC OPT calls up the screen which allows setting of parameters which are related to the Voice On the
control option. This function will only be visible when a codeplug wIth the Voice On Control option has been
read.
F10 -HELP moves the display backward in the RSS tree, one screen or menu at a time.
Fields are defined on the following page.
6.2.2.1 TRUNKING RADIO WIDE OPTIONS
RSS LOCATION: At the CHANGE/VIEW MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
MENU:CHANGE/VIEW:TRUNKING:WIDE OPTIONS
Use UP/DOWN Arrows to Select Choice.
TRUNKING RADIO WIDE OPTIONS
Telephone Interconnect ....................Half Duplex
ISW Window Adjust .........................................41
Auto Dial Holdoff (ms)..................................2525
RF Modem .............................................Disabled
F1
HELP
F2
SMRTZN
ENV
F3
VOC
OPT
F4 F5 F6 F7 F8 F9 F10
EXIT
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Press F2. The TRUNKING RADIO WIDE OPTIONS screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
The options and parameters on this menu apply to all trunking operation, independent of system, personality, or
talkgroup. Other radio wide options that apply to both conventional and trunking operation are located on the
Radio Wide Options screen (F4/F3/F2). Conventional options are located on the Conventional Radio Wide
Options screen.
