2.8.3 Anatomy of a Screen
As stated before, the only difference between a menu and a screen is the contents of the working area, shown as
letter C in the previous menu figure, and shown below as the Working area. Screens list features (fields) that can
be viewed or edited.
The working area of a screen contains a list of programmable features called “fields” that can be selected or
changed using the arrow, tab or return keys described earlier. On some screens are features that can be selected
for each
individual
channel (hereafter we will refer to a channel as a “mode”); these features are selected on a
“per-mode” basis. On other screens are features that can be selected for
all
modes of the radio (“radio-wide”
features).
Figure 2-8. An RSS Screen
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:CONV:PERS
Enter or Scroll to Select
Personality.
Personality................1 CONVENTIONAL PERSONALITY
Receive Only .................................Disabled Signalling ............................................MDC
Direct / Talkaround .........................Enabled MDC System #.......................................1
Time Out Timer.............................3 - 60 PTT ID........................................Disabled
Scan List .............................................None Emergency..................................Enabled
Hot Keypad....................................Disabled Revert...............................Selected Chan
Phone Operation...........................Unlimited
Receive
Transmit Direct
Frequency (MHz) 935.06250 896.01250 896.01250
Signalling Type CSQ PL DPL
Code 67.0 Hz XZ 023
F1
HELP
F2
ADD
PERS
F3
PREV
PERS
F4
NEXT
PERS
F5
DELETE
PERS
F6 F7
MDC
OPTIONS
F8
PHONE
OPTIONS
F9
MORE
OPTIONS
F10
EXIT
