MOTOROLA Radio Service Software
MTSX Model:
MAIN:GET/SAVE/PROG:CLONE RADIO
Select Function F1 - F10
NEW TRUNKING IDS
Serial Number.......................
System Type I II/IIi Universal
Pers # System Key Type # ID Flt/ATG Indv ID Indv ID ID
01 Disabled II 01 0001 000F
02 Disabled IIi 01 0001 0001
03 Disabled I 02 0001 0001
F1
HELP
F2
READ
SER NUM
F3
CONV
ID
F4
LIMITED
CLONE
F5 F6
DUPLICATE
II/III ID
F7
SAVE
FILE
F8
PROGRAM
RADIO
F9 F10
EXIT
This screen is used to copy codeplug information from one radio to another one. Only radios with the same model
number may be cloned. This screen summarizes the individual ID information for both MDC and Trunking so that
it can be changed from one convenient screen. Conventional radios may be cloned completely. Trunking radios
may only be cloned if you have a system key for every trunking system in the codeplug.
Full Cloning:
System keys for all Trunked Systems in the radio are required to perform a full clone. Follow the steps below for
Full Cloning procedures.
1. Use the GET/SAVE functions to read (F3/F2) the radio codeplug to be cloned. That is the “source”
codeplug. An archive file may also be used as the “source” codeplug.
2. Enter the serial number of the radio to be cloned on the TRUNKED CLONING screen, or press F2 to read the
serial number from the connected radio. System keys are required to change the serial number.
3. Change the trunking individual IDs to those required by the new radio on this screen. If MDC IDs are used
also, they can be changed on the MDC ID screen by pressing F3.
4. Connect the “target” radio to the computer, and press the F8 function key to program the “source” codeplug
into the “target” radio.
PROGRAMMING PROCEDURE:
1. Press F3 at the MAIN MENU. The GET/SAVE/PROGRAM MENU appears.
2. Press F5. The TRUNKED CLONING screen appears.
3. Select the desired function key (F1 - F10).
