MTSX RSS GET/SAVE/PROGRAM
68P81074C50 5-3
MOTOROLA Radio Service Software
MTSX Model:
MAIN:GET/SAVE/PROG:READ RADIO
READ RADIO CODEPLUG
Reading Codeplug Block 1 of 34
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
5.2.1 READING CODEPLUG DATA
You may read the codeplug from the radio or from the archive disk. After reading, the codeplug will be checked
for valid serial number, model number, check sums, etc.
5.2.1.1 READING CODEPLUG DATA FROM THE RADIO
(Requires RIB)
RSS LOCATION: At the GET/SAVE/PROGRAM MENU, press .
0%
100%
To read codeplug data from the radio, press F2 (READ RADIO function) at the GET/SAVE/PROGRAM MENU;
the READ RADIO CODEPLUG screen will appear (refer to the screen shown above). A series of status
messages will appear in the upper right corner of the screen. If a communication error occurs, a pop up window
will be displayed. If no errors occur, the center of the screen will display the progress of the codeplug read. The
read process will take approximately one minute, depending on the type of computer and the size of the
codeplug being read. After the codeplug is read, the GET/SAVE/PROGRAM MENU will be displayed.
FIELD DEFINITION:
Reading Codeplug Blocks This is the number of blocks that have been read. The status bar shows the relative
value of the number of blocks read so far compared to the total number of blocks to be read.
PROGRAMMING PROCEDURE:
1. Press F3 at the MAIN MENU. The GET/SAVE/PROGRAM MENU appears.
2. Press F2. The READ RADIO CODEPLUG screen appears.
