MTSX RSS CHANGE/VIEW
68P81074C50 6-15
FIELD DEFINITIONS:
WARNING
DO NOT DUPLICATE A FUNCTION ON MULTIPLE
CONTROLS, I.E., A BUTTON AND A SWITCH, OR A
SWITCH AND A MENU. THIS MAY CAUSE THE RADIO
TO MALFUNCTION, AND CAN CAUSE OPERATOR
CONFUSION.
Conventional Buttons:
Blank - No function. No tone will sound.
Chan/Sub Select – Change Channels (Rotary Only)
Call Response - Is used to respond to a private call, or call alert, or phone call. This function should be used
for ‘Response Only’ radios, or in conjunction with the Phone/Private Call functions assigned to the Menu.
Dynamic Priority – Increases the priority of the current active channel.
Emergency – Activates an Emergency transmission. [2] (Not Available on All Models).
Light – Turns on the display light.
Nuisance Delete – Removes the current active channel from the list.
Monitor – Radio will unsquelch when the button is pressed, allowing you to listen to activity on the channel.
Page - Select Call Alert ID. [2]
Phone – Enables the DTMF Encoder. [1]
Rptr Acc Button 1 and 2 - Repeater Access Button 1 and 2 are used to manually send a repeater-access
request code.
Scan – Enables / Disables Scan. [1]
Select Call - Select Selective Call ID. [2]
Talkaround/Direct – Enables / Disables Talkaround for transmit.[1]
Unprogrammed – No function. A bad key chirp tone will sound.
Volume Set Tone – Generates a tone when pressed. Used for volume knob adjustment.
Zone/Sys – Change Zones (Rotary Only)
NOTES
[1] For the radio to function properly, this feature must also be enabled on the
Conventional Personality screen (F4/F6/F3).
[2] For the radio to function properly, this feature must also be enabled on the MDC
System screen (F4/F6/F4/F3).
