CHANGE/VIEW MTSX RSS
6-26 68P81074C50
6.2.1.3.2 DIALing OPTIONS
RSS LOCATION: At the CHANGE/VIEWMENU,press .
FUNCTION KEY DESCRIPTIONS:
F1 - HELPprovides useful information about the currently displayed menu, screen, or field.
F10 - EXITmoves the display backward in the RSS tree, one screen or menu at a time.
Fields are defined on the following page.
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:CONFIG:PHONE:DTMF
Enter or Scroll to Select Value.
DIALING OPTIONS
Phone Dialing...............Delayed Buffered DTMFPause Time (ms)........................1000
DTMF Digit Hangtime (ms)...............1000
Num Initial Delay Digit Duration Interdigit Delay
(ms) (ms) (ms)
___________ ___________ ____________ _____________
1 250 150 100
2 250 150 100
3 250 150 100
4 250 150 100
F1
HELP
F2 F3 F4 F5 F6 F7 F8 F9 F10
EXIT
F3
F4
PROGRAMMING PROCEDURE:
1.Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2.Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3.Press F4. The PHONE CONFIGURATION screen appears.
4.Press F9. The DIALING OPTIONS screen appears
5.Press Tabto select the desired field, or press the desired function key (F1 - F10).
6.If a field is selected, press the up/down arrow keys to select choice or value.
This screen allows you to modify the DTMF phone wide parameters such as timing and phone dial operation.
NOTE
For non-keypad models-This option can ONLY be used with
the One Touch Button Feature (Main Menu F4/F4/F3/F9/F5).
Each trunking and conventional system uses one of these parameter sets which are selected in the DTMF
Access Timing table field on the CONVENTIONAL PERSONALITYPHONE OPTIONSscreen (F4/F6/F3/F8), and
in the Phone DTMF Timing field on the TRUNKING SYSTEM OPTIONSscreen (F4/F4/F3/F9).
F9
To Next Page
