CHANGE/VIEW MTSX RSS
6-48 68P81074C50
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:TRUNKING:SYSTEM
Use UP/DOWN Arrows to Select Type.
System........................2 TRUNKING SYSTEM
System Key. ..................................Disabled
System Type..........................................II/IIi
System ID............................................0001
Alias............................................Disabled
Individual ID .....................................1-0001
Connect Tone (Hz)......................#0-105.88
Coverage Type..............................Disabled
Affiliation Type ................................On PTT
Dynamic Regrouping......................Enabled
Zone................0 Chan................0
Remote Monitor...............................Enabled
RM Base Time.......................................15
F1
HELP
F2
ADD
SYSTEM
F3
PREV
SYSTEM
F4
NEXT
SYSTEM
F5
DELETE
SYSTEM
F6
CONTROL
CHANNEL
F7 F8 F9
MORE
OPTIONS
F10
EXIT
TRUNKING SYSTEM Screen for System 2, Type II/IIi
RSS LOCATION: At the CHANGE/VIEW MENU, press .
A Trunking System refers to a specific repeater site, the system ID, the individual radio ID for that System, the
control channel frequencies, and the connect tone required to operate on that System.
Each system that the radio is programmed to operate on is ‘linked’ to one or more trunking personalities. The
personality defines the features available for the radio while operating on that system. Each radio is uniquely
identified on each system by its individual ID.
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Press F3. The TRUNKING SYSTEM screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
To Next Page
