MTSX RSS CHANGE/VIEW
68P81074C50 6-55
6.2.2.2.2 CONTROL CHANNEL
RSS LOCATION: At the CHANGE/VIEW MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
....TRUNKING:SYSTEM:CONTROL CHANNEL
Enter or Scroll to Select System.
System......................................1
CONTROL CHANNELS
Number Frequency
1 851.0125
F1
HELP
F2
ADD
CHAN
F3
PREV
SYS
F4
NEXT
SYS
F5
DELETE
CHAN
F6 F7 F8 F9 F10
EXIT
This screen allows you to change or view the control channels for this particular system.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - ADD CHAN allows you to add a channel.
F3 - PREVIOUS SYS allows you to go to the system before the current one.
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Press F3. The TRUNKING SYSTEM screen appears.
4. Press F6. The CHANNEL ASSIGNMENT DATA screen appears.
5. Press F6. The CONTROL CHANNELS screen appears.
6. Press Tab to select the desired field, or press the desired function key (F1 - F10).
7. If a field is selected, press the up/down arrow keys to select choice or value.
