Configure System Information
102
M4100 Series Managed Switch
8. Use Interface to select the ports on which LLDP-MED frames can be transmitted.
The following table describes the LLDP-MED Local Device Information fields.
Table 29. LLDP-MED local device information
Field Description
Network Policy Information: Specifies if the network policy TLV is present in the LLDP frames.
Media Application Type The application type. Types of applications are unknown,
voicesignaling, guestvoice, guestvoicesignalling,
softphonevoice, videoconferencing, streammingvideo,
and vidoesignalling.
Each application type that is received has a VLAN ID,
priority
, DSCP, tagged bit status, and unknown bit status.
A port can receive one or many such application types.
Only when a network policy TLV was transmitted, is this
information be displayed
Inventory: Specifies if the inventory TLV is present in LLDP frames.
