NETGEAR M4100 Series User Manual

Configure Switching Information
133
M4100 Series Managed Switch
3. Launch a web browser.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Switching
 VLAN  Advanced  Protocol Based VLAN Group Membership.
8. Use Group ID to select the protocol-based VLAN group ID.
9. Use Port List to add the ports you selected to this protocol-based VLAN group.
A given interface can belong to only one group for a given protocol. If you already added
a port to a group for IP
, you cannot add it to another group that also includes IP, although
you could add it to a new group for IPX.
The following table describes the nonconfigurable information displayed on the screen.
Table 41. Protocol-Based VLAN Group Membership
Field Description
Group Name This field identifies the name for the protocol-based VLAN you
selected. It can be up to 32 alphanumeric characters long, including
blanks.
Current Members This button can be click to show the current numbers in the selected
protocol-based VLAN group.
