NETGEAR M4100 Series User Manual

Configure Switching Information
159
M4100 Series Managed Switch
7. Select Switching  STP  Advanced  MST Port Status.
Note: If no MST instances were configured on the switch, the screen
displays a No MSTs Available message and does not display the
fields shown in the field description table that follows.
8. Use MST ID to select one MST instance from existing MST instances.
9. Use Interface to select one of the physical or port channel interfaces associated with VLANs
associated with the selected MST instance.
10. Use Port Priority to specify the priority for a particular port within the selected MST
instance.
The port priority is set in multiples of 16. For example if the priority is any value between
0 and 15, it is set to 0. If you try to set it to any value between 16 and (2*16–1), it is set to
16, and so on.
11. Use Port Path Cost to set the path cost to a new value for the specified port in the selected
MST instance.
It takes a value in the range of 1 to 200000000.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
