Manage Device Security
368
M4100 Series Managed Switch
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Security
ACL > Advanced VLAN Binding Table.
8. To delete a VLAN ACL-to-interface binding, select the check box next to the interface and
click the DELETE button.
9. Use ACL T
ype to specify the type of ACL.
The valid ACL types include IP ACL, MAC ACL, and IPv6 ACL.
10. Use ACL ID to display all the
ACLs configured, depending on the ACL type selected.
The following table describes the information displayed in the ACL VLAN Binding T
able.
Table 98. ACL VLAN Binding Table
Field Description
Direction The packet filtering direction for the ACL.
VLAN ID The VLAN ID for ACL mapping.
Sequence Number An optional sequence number can be specified to indicate the order of
this access list relative to other access lists already assigned to this
VLAN and direction.
A lower number indicates higher precedence
order. If a sequence number is already in use for this VLAN and
direction, the specified access list replaces the currently attached
access list using that sequence number. If the sequence number is not
specified by the user (for example the value is 0), a sequence number
that is one greater than the highest sequence number currently in use
for this VLAN and direction is used. The valid range is 1 to
4294967295.
