Monitoring the System
390
M4100 Series Managed Switch
operation log. The system operation log stores the last N messages received during system
operation.
 To configure persistent logs:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Monitoring
 Logs > Persistent Logs.
8. To enable or disable logging, select the Admin Mode Enable or Disable radio button.
A log that is disabled does not log messages.
9. In the Behavior menu, select a log severity level.
A log records messages equal to or above a configured severity threshold. These
severity levels are available:
severity levels are available:
• Emergency (0).
The system is unusable
• Alert (1).
Action must be taken immediately
• Critical (2). Critical conditions
• Error (3). Error conditions
• W
arning (4). Warning conditions

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
