GENESYS User Manual Issue 1
EXT 3 & EXT 4
When selected, will light yellow and select either of the Stereo External
inputs to the monitor system.
D-EXT led
The D-EXT led will light on the second press of EXT 2.
It is possible to have two sets of six-wide Externals on EXT 2.
The second set can be selected by pressing the EXT 2 button again.
> 1st press takes the 1st set of External feeds from the Analogue inputs
(EXT 2 will light)
> 2nd press takes the 2nd set of External feeds from the Digital Inputs (if
present, EXT 2 and the D-EXT led will light)
The D-EXT led will only light if an AD/DA cassette has been detected.
If there is no cassette, it will not be possible to select D-EXT.
INT
Lights yellow when selected and makes possible the selection of the
internal monitors (Auxes, Cues etc) to the control room loudspeakers.
EXT
Will light yellow when selected, and makes possible the selection of the
External monitors (EXT 1 etc) to the control room loudspeakers.
INT and EXT are interlocked.
If SUM is selected, the interlock between INT and EXT is cancelled.
SUM
Lights yellow when selected and affects the INT and EXT as described
above, so a collection of Internal and External sources can be heard at
once.
It will also enable all of the internal and external LS buttons (including
INT and EXT monitor selections) to be turned on and off individually.
In this mode, 8T and 2T will still be interlocked.
INS
Lights yellow and activates the Monitor inserts.
ST (or Downmix)
Collapses the 5.1 monitor mix into a stereo by sending L to L, R to R, C to
L & R, S to L & R (this can also be turned on or off), LS to L and RS to R.
It is possible to tie monitoring the stereo downmix to a particular set of
loudspeakers. See section below on SEL Mode.
ØL
Inverts the phase of the Left side of the monitoring.
- 47 -
