GENESYS User Manual Issue 1
Timecode
(XLR)
1 Screen
2 Hi
3 Lo
RS 232
(9-way D-type)
Relays 1 & 2 are a closing set
of contacts operated by the
EXT button (by the DAW
Screen).
This facility is used for
switching the VGA feeds (one
each from Genesys and the
DAW) to enable the system to
operate on one TFT screen for
both machines.
VGA
(Hi-density 15-way D-type)
1 Red 0 – 0.7v
2 Green 0 – 0.7v
3 Blue 0 – 0.7v
4 N/C
5 Digital ground
6 Red Return Analogue ground
7 Green Return Analogue ground
8 Blue Return Analogue ground
9 N/C
10 Digital ground
11 N/C
12 N/C
13 Horizontal sync TTL
14 Vertical sync TTL
15 N/C
- 83 -
1 Ext RS 485 (depending on jumper configuration)
2 RS 232 Receive
3 RS 232 Transmit
4 Relay 1
5 Signal Ground
6 Ext RS 485+ (depending on jumper configuration)
7 RTS or GND (depending on jumper configuration)
8 Clear to Send
9 Relay 2
