Neve Genesys - Console Connector pin-outs

GENESYS User Manual Issue 1
Console Connector pin-outs
Computer Cassette
USB
1 +5v Red
2 - Data White
3 + Data Green
4 GND Black
Mouse
(PS2)
1 - Data
2 N/C
3 GND
4 +5v
5 + Data / Clock
6 N/C
Shell Shield
Keyboard
(PS2)
1 Keyboard data (+5v signal level)
2 Keyboard reset (not used)
3 Ground (0v)
4 +5v
5 Keyboard clock (+5v signal)
6 N/C
Shell Shield
RJ 45
(Twisted pair networking)
1 TX +
2 TX -
3 RX +
4 BD3 +
5 BD3 -
6 RX -
7 BD4 +
8 BD4 -
- 82 -
