GENESYS User Manual Issue 1
AFL/PFL led
This yellow led flashes if a Channel SOLO (with CH SAFE selected), or a
Monitor SOLO (with MON SAFE selected) is pressed.
It will also light if an 8T SOLO (tied to the Channel or Monitor Safe
buttons via the setup screen) is pressed, or if any of the AFL buttons on
the Rev returns are selected.
PFL
Lights yellow and allows the PFL bus to be switched to the monitors
whenever a SOLO is pressed on a Channel, Monitor or 8T (depending on
8T Linking).
It is enabled to be selected by either CH SAFE or MON SAFE and is
interlocked with SIF.
It will be temporarily cancelled if any Rev Return AFL is selected.
SIF
Lights yellow and allows the Solo In Front to be switched into the monitor
when Channel, Monitor, Rev AFL or 8T SOLO buttons are pressed
(dependent on 8T linking).
It is enabled by either CH SAFE or MON SAFE and is interlocked with
PFL.
M2 SEL
Lights yellow when selected and allows PFL or the RTB to be sent to the
M2 speakers if they are not being used for other monitoring purposes.
> The 1st press will send the PFL bus to M2 anytime a Solo button is
pressed on the console.
> The 2nd press will set RTB to be sent to M2.
> The 3rd press will return the M2 speakers to their default state.
The function of M2 SEL will be shown on the associated leds.
M2 SEL will be temporarily suspended if M2 is selected, and will return to
it's original state if M2 is deselected.
SWP
Lights yellow and sends the rear Left and Right speakers to the front Left
and Right, cutting all other speakers.
This enables the rear Surround image to be heard on the front speakers.
A, B, M1 & M2
Lights yellow when pressed and selects sets of loudspeakers.
• A and B are both Surround sets of speakers.
• M1 and M2 are both Stereo sets of speakers.
The M1 speaker outputs appear on XLRs on the rear of the console for
convenience.
It is possible to tie a set of loudspeakers to the Stereo fold-down as
described in ST, and also which speaker set is locked to the Sub and Left
Surround / Right Surround.
See section below on SEL Mode.
S & LS/RS leds
Lights red whenever B, M1 or M2 loudspeaker sets are selected with ties
set, either on the LS Settings Screen or using SEL Mode and the LS
selector buttons.
- 48 -
