GENESYS User Manual Issue 1
Appendix A – Processing Cassettes Switch Settings
On each of the EQ and Dyn cassettes, there is a block of eight dip-
switches, the first three of which need to be set so that each card is
addressed correctly.
The switch settings below are the same for both EQ and DYN cassettes.
Board ID
Board ID
Position ID SW 1 SW 2 SW 3
1 - 8 0 Off Off Off
9 - 16 1 ON Off Off
17 - 24 2 Off ON Off
25 - 32 3 ON ON Off
33 - 40 4 Off Off ON
41 - 48 5 ON Off ON
49 - 56 6 Off ON ON
57 - 64 7 ON ON ON
On later versions of the EQ and Dyn cassettes, there will be no need to set
the dip switches as the communication protocol has changed.
- 98 -
NB:
The presence of these
switches mean that
cassettes cannot just be
removed from one section
of the console and then
reinserted into another at
will.
Cassettes may still be
moved, but they will not
function correctly unless
these three switches are
set to reflect their new
position in the console.
