VBA23001-R.3762 .A
- D58 ･ D90 -
・Peel off the double-stick tape (#781).Peel off the double-stick tape (#781).
・Remove the insulation sheet (#270).Remove the insulation sheet (#270).
・Peel off the double-stick tape (#780).Peel off the double-stick tape (#780).
・Remove the penta prism retainer (#267) and the protection sheet (#269).Remove the penta prism retainer (#267) and the protection sheet (#269).
・Remove the penta prism (#4) and the view field frame 2 (#264).Remove the penta prism (#4) and the view field frame 2 (#264).
Double-stick tape (#781)
Insulation sheet (#270)
Double-stick tape (#780)
Penta prism retainer (#267)
Protection sheet (#269)
Penta prism (#4)
View field frame 2 (#264)
To Next Page
