VBA23001-R.3762 .A
- D59 ･ D90 -
・Take out the four screws (#635).Take out the four screws (#635).
・Remove the two plates (#532) and the penta prism FPC unit (#B1021).Remove the two plates (#532) and the penta prism FPC unit (#B1021).
Plate (#532)
×
2
Penta prism FPC unit (#B1021)
Screw (#635)
×
4
・Remove the spacer (#535).Remove the spacer (#535).
Spacer (#535)
Penta prism FPC unit
INC
