Nordson EFD E2 - Specifications

E Series Automated Dispensing System
12 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Specifications
Item/Model E2 E3 E4 E5 E6
Number of axes 3 3 3 3 3
Maximum working
area (X / Y / Z )
200 / 200 / 50 mm
(8 / 8 / 2")
300 / 300 / 100 mm
(12 / 12 / 4")
400 / 400 / 100 mm
(16 / 16 / 4")
500 / 500 / 150 mm
(20 / 20 / 6")
620 / 500 / 150 mm
(24 / 20 / 6")
Workpiece
payload
5 kg (11.0 lb) 10 kg (22.0 lb) 10 kg (22.0 lb) 10 kg (22.0 lb) 10 kg (22.0 lb)
Tool payload 3 kg (6.6 lb) 5 kg (11.0 lb) 5 kg (11.0 lb) 5.5 kg (7.7 lb) 5 kg (11.0 lb)
Unit weight 21 kg (46 lb) 39.5 kg (87 lb) 44.5 kg (98 lb) 47 kg (107 lb) 50 kg (110 lb)
Dimensions
370
Wx510Hx414D mm
(15
W x 20H x 16"D)
490
Wx644Hx519D mm
(19
W x 25H x 20"D)
590
Wx644Hx617D mm
(23
W x 25H x 24"D)
690
Wx814Hx718D mm
(27
W x 32H x 28"D)
808
Wx812Hx718D mm
(32
W x 32H x 28"D)
Maximum speed
(XY / Z)
500 / 250 mm/s
(20 / 10"/s)
800 / 320 mm/s
(31 / 13"/s)
800 / 320 mm/s
(31 / 13"/s)
800 / 320 mm/s
(31 / 13"/s)
800 / 320 mm/s
(31 / 13”/s)
Drive system
3-phase micro-
stepping motor
3-phase micro-
stepping motor
3-phase micro-
stepping motor
3-phase micro-
stepping motor
3-phase micro-
stepping motor
Memory capacity
1-99 programs
1-9,999 points per
program
1-99 programs
1-9,999 points per
program
1-99 programs
1-9,999 points per
program
1-99 programs
1-9,999 points per
program
1-99 programs
1-9,999 points per
program
Data storage USB USB USB USB USB
General purpose
I/O
8 inputs / 8 outputs 8 inputs / 8 outputs 8 inputs / 8 outputs 8 inputs / 8 outputs 8 inputs / 8 outputs
Drive method PTP and CP PTP and CP PTP and CP PTP and CP PTP and CP
Dispensing
controller
External External External External External
Power supply
Auto-switching,
AC100–240V, 200 W
Auto-switching,
AC100–240V, 320 W
Auto-switching,
AC100–240V, 320 W
Auto-switching,
AC100–240V, 320 W
Auto-switching,
AC100–240V, 320 W
Interpolation 3 axes (3D space) 3 axes (3D space) 3 axes (3D space) 3 axes (3D space) 3 axes (3D space)
Repeatability* ±0.008 mm/axis ±0.008 mm/axis ±0.008 mm/axis ±0.008 mm/axis ±0.008 mm/axis
Working
temperature
10–40° C (50–104° F) 10–40° C (50–104° F) 10–40° C (50–104° F) 10–40° C (50–104° F) 10–40° C (50–104° F)
Teach Pendant Included Included Included Included Included
Tip alignment kit Optional Optional Optional Optional Optional
Approvals CE, RoHS, WEEE, China RoHS
*Repeatability results may vary depending on the method of measurement.
RoHS标准相关声明 (China RoHS Hazardous Material Declaration)
产品名称
Part Name
有害物质及元素
Toxic or Hazardous Substances and Elements
铅 
Lead
(Pb)
汞 
Mercury
(Hg)
镉 
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr6)
多溴联苯
Polybrominated
Biphenyls
(PBB)
多溴联苯醚
Polybrominated
Diphenyl Ethers
(PBDE)
外部接口
External Electrical
Connectors
X 0 0 0 0 0
O:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准低于SJ/T11363-2006限定要求。
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is below
the limit requirement in SJ/T11363-2006.
X:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准高于SJ/T11363-2006限定要求.
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is above
the limit requirement in SJ/T11363-2006.
WEEE Directive
This equipment is regulated by the European Union under WEEE Directive (2012/19/EU). Refer to
www.nordsonefd.com/WEEE for information about how to properly dispose of this equipment.
