Fixture Plates
All plates include four edge levelers and four leveling mounts.
Part Number Description
7028276 200 mm xture plate
7028277 300 mm xture plate
7028278 400 mm xture plate
7028279 500 mm xture plate
Start / Stop Box
The start / stop box accessory facilitates input / output connections for remote functions, such as
an start or emergency stop button. Refer to “Example Input / Output Connections” on page88 for
schematics.
Part Number Description
7363285 Start / stop accessory box and I/O checker, standard
The I/O checker allows a user / programmer to simulate either (1) input signals
from external devices or (2) outputs from the automation before physically installing
any external devices.
7360865 Start / stop accessory box, European Community
Tip Alignment Kit
Part Number Description
7360892 E Series robot tip alignment accessory kit
Accessories (continued)
Height Sensor
The optional height sensor can detect any variation from the original Z-height program values from workpiece to
workpiece. If the Zheight changes, the system detects the new Z-height value adjusts the program accordingly.
Refer to “Appendix D, Height Sensor Setup and Use” on page128 to install and use the height sensor.
Part # Description
7361667 Height sensor accessory kit, E / EV Series
