Appendix A, Type Menu Reference
This appendix provides detailed information for each setup and dispense command under the Type menu.
Commands are listed in the same numerical order as they are in the Type menu.
The following rules apply to all commands:
• A command is in effect until it is superseded by another command.
• Command settings override system settings.
01 Dispense Dot
Dispense Dot 1/3
------------------------------
X: 130.93 mm
Y: 37.39 mm
Z: 45.54 mm
[F1] OK [F2] Next [F3] Current
Dispense Dot 2/3
------------------------------
Dispense Time: 0.100 s
Dwell Time: 0.00 s
[F1] OK [F2] Next
Dispense Dot 3/3
------------------------------
Retract Distance: 100.00 mm
Retract Low: 10.0 mm/s
Retract High: 10.0 mm/s
[F1] OK [F2] Next
Key Press Function
>
Registers the current XYZ location as a Dispense Dot point.
Parameter Description
Dispense Time Duration the dispenser signal is initiated ON.
Range: 0.001–1000.0 (s)
Dwell Time The delay time that occurs at the end of dispensing to allow the pressure to equalize
before the tip moves to the next point.
Range: 0.01–1000.0 (s)
Retract Distance The distance the tip raises after dispensing.
Retract Low The speed at which the tip raises after dispensing.
Range: 0–200 (mm/s)
Retract High After the tip raises the amount specied by Retract Distance at the speed specied
by Retract Low, the tip continues raising to the ZClearance at the speed (in mm/s)
specied by this setting. The purpose of specifying a ZClearance is to allow the tip to
raise high enough to clear any obstacles it encounters on its way to the next point. Refer
to “13ZClearance” on page101.
Range: 30–200 (mm/s)
