Teach Pendant Menu Item Descriptions
This section provides a brief description of all the Teach Pendent menu items for quick reference as needed.
Program Menu
[PROGRAM MENU] 1/1
01 Teach/Run
02 Program List
03 Reset Counter
04 Program Offset
05 Needle Adjust
06 Auto Needle Adjust
Menu Item Description
01 Teach/Run Used to toggle between the Teach Mode and the Run Mode.
NOTE: If a program is locked, the Teach Mode is password-protected.
02 Program List Used to select a program number from 1 to 99.
03 Reset Counter Resets the dispense cycle count.
NOTE: This function is password-protected.
04 Program Offset Adjusts the XY coordinates for all dispense commands in a program when
you enter offset values for each axis. For this function to work properly, the
program must contain two Mark Points. Refer to “How to Set Mark Points” on
page52 and to “How to Adjust All Points in a Program (Program Offset)” on
page53.
05 Needle Adjust Calibrates the tip height after a dispensing tip or syringe barrel change on
systems without the optional tip alignment kit. For this function to work
properly, you must set a Calibration Point. Refer to “Calibrating the Tip Height”
on page70.
06 Auto Needle Adjust Calibrates the tip height after a dispensing tip or syringe barrel change on
systems with the optional tip alignment kit. For this function to work properly,
you must calibrate the tip detector. Refer to “Calibrating the Tip Height” on
page70.
