Setup Menu
[SETUP] 1/3
01 XY Move Speed
02 Z Move Speed
03 Point to Point Arc Jump
04 Park Position
05 Calibration Point
06 Mark Points
07 Program Output Status
[SETUP] 2/3
08 Pause Status
09 Auto Purge
10 Pre-cycle Initialize
11 Pre-dispense Wait Time
12 Default Dispense Port
13 Needle Detect Setup
14 Run Limit
[SETUP] 3/3
15 Measurement Unit
16 Password Setup
17 Remote Command
18 Height Sensor
19 Language
20 System Information
Menu Item Description
01 XY Move Speed Sets the speed of the of X and Y axis movement:
• Maximum XY speed: 500 (mm/s) (E2); 800 (mm/s) (E3, E4, E5, E6)
• Default: 100 (mm/s)
02 Z Move Speed Sets the speed of the of Z axis movement:
• Maximum Z speed: 250 (mm/s) (E2); 320 (mm/s) (E3, E4, E5, E6)
• Default: 50 (mm/s)
03 Point to Point Arc Jump Enables or disables tip movement in an arc motion between dispense
patterns:
• 1 Enable: The tip moves in an arc motion.
• 2 Disable (default): The tip moves in a square motion.
04 Park Position Sets the Park Position XYZ coordinates. When the Park Position command
is used in a dispense program, the tip moves to the set Park Position. The tip
also moves to the Park Position at the end of a dispense program.
• Default: 0, 0, 0 (mm)
05 Calibration Point Sets a reference point that is used by the system to perform the Needle Adjust
function.
06 Mark Points Sets two reference points that are used by the system to perform the Program
Offset function.
07 Program Output Status Enables or disables how outputs function after a program ends:
• 1 Enable: The system keeps outputs ON after a program ends.
• 2 Disable (default): The system allows outputs to switch OFF after a
program ends.
08 Pause Status Sets the position that the tip moves to when you press the START button to
pause the current dispense cycle:
• 1 Park Position (default): The tip moves to the user-specied Park Position.
• 2 Stand: The tip stays at the current position.
09 Auto Purge Used to set up parameters for purging. Refer to “Auto Purge” on page39.
• Purge time: 100.0 (s) maximum
• Wait time: 999 (s) maximum
Continued on next page
