Operation (continued)
Pausing During a Dispense Cycle
Press START at any time to pause the system during a dispense cycle; the tip moves to the location specied by
Pause Status or stops at the next program point.
NOTE: If the system is paused during dispensing, the system shuts off the dispenser, compromising pattern
integrity.
Purging the System
To purge the system, press the DISPENSER PURGE button.
NOTE: You can set up the system to purge automatically. Refer to “Auto Purge” on page39.
Shutting Down the System
1. Refer to the dispensing system operating manuals for any special shutdown instructions.
2. Switch off the robot.
Part Numbers
Part # Part # Europe* Description
7360852 7361345 Robot, E2, 200 x 200 x 50 mm (8 x 8 x 2”)
7360853 7361346 Robot, E3, 300 x 300 x 100 mm (12 x 12 x 4”)
7360854 7361347 Robot, E4, 400 x 400 x 100 mm (16 x 16 x 4”)
7360855 7361348 Robot, E5, 500 x 500 x 150 mm (20 x 20 x 6”)
7362101 7362102 Robot, E6, 620 x 500 x 150 mm (24 x 20 x 6”)
*Complies with European safety regulations.
