E Series Automated Dispensing System
50 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Working with Programs and Commands (continued)
How to Change a Group of Addresses (Group Edit) (continued)
# Key Press Step Teach Pendant Display
Step 3, continued from previous page
6 — Changes the Z Value for all
selected addresses to the absolute
Z value.
7 — Changes the XYZ values for
all selected addresses by the
specied offset value.
8 — Changes the XYZ values for all
selected addresses by allowing
you to jog the tip from its current
location to a new location. The
difference between the two
locations determines the offset
value.
Group Edit 1209-1254 1/2
------------------------------
1 Copy 5 Line Speed
2 Delete 6 Z Value
3 Move 7 Point Offset
4 Dispense Time 8 Offset To
Select: _
[F1] OK [F2] Next
9 — Changes the XYZ values for all
selected addresses by ipping
points along the X axis or the
Yaxis. Refer to “Example
Illustrations of Mirror Points and
Rotate Points” on page51 for an
example.
10 — Rotates the tip the specied
number of degrees (±180°) for all
selected addresses. Before this
occurs, the system prompts you
to jog the tip to a starting point (or
rotation origin). Refer to “Example
Illustrations of Mirror Points and
Rotate Points” on page51 for
an example.
Group Edit 1209-1254 2/2
------------------------------
9 Mirror Points
10 Rotate Points
Select: _
[F1] OK [F2] Next
4
• Press F1 to continue and follow the
instructions on the display to complete
the selected action for the specied
range of addresses.
5
• When done, press F1 again to save or
exit.
