E Series Automated Dispensing System
62 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Creating Patterns (continued)
How to Make a Line (continued)
# Key Press Step Teach Pendant Display
7
• Jog the tip to the XYZ location of for the
last dispense point (Line End).
8
>
• Press SHIFT > 3 to register the location
as a Line End point.
• Make XYZ coordinate changes as
needed.
Line End 1/4
------------------------------
X: 130.93 mm
Y: 37.39 mm
Z: 45.54 mm
[F1] OK [F2] Next [F3] Current
9
>
• Press F2 to move through the Line End
parameter screens.
• Press F1 to save and exit.
Line End 4/4
------------------------------
Retract Distance: 0.00 mm
Retract Low: 20.0 mm/s
Retract High: 80.0 mm/s
[F1] OK [F2] Next
10
>
• Press SHIFT > END to register the end
of the program.
11
• Press START to run the program.
