7-24 Service Manual
XZAC4219-05
5. Back off the lock-screws (1) of the motherboard.
Figure 7 - 31 Fastening screws of motherboard
6. Disconnect the cable of the standard serial interface (1).
Figure 7 - 32 Cable of the standard serial interface
NOTE: if present disconnect the cable of the optional serial interface.
1
1
1
1
Printers with serial number
8.xxx.xxx Printers with serial number 1.xxx.xxx
1
1
Printers with serial number 8.xxx.xxx Printers with serial number 1.xxx.xxx
