MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-17 Other Outputs
H
H-17-9 Trend Analysis Output 3
 Use as External Illumination Strobe
Output On Output 3
Usage: This option provides discrete signalling to host software to control external
devices such as PLCs and relays. It is useful for routing, sorting, and
preventing mis-packaging and mis-routing.
Definition: Sets the discrete output functions for specific user-selected conditions.
Allows the user to determine when an output (or outputs) will be activated.
Serial Cmd:
< K812, output on,output state,pulse width,output mode >
Default: Mismatch or No-Read
Options: 0 = Mismatch or No-Read
1 = Match (or Good Read)
2 = Mismatch
3 = No-Read
4 = Trend Analysis
5 = Symbol Quality
6 = Diagnostic Warning
7 = In Read Cycle
8 = Use as External Illumination Strobe
Definition: Asserts the external illumination strobe output during image capture.
H-17-9 Trend Analysis Output 3
Serial Cmd: < K782, trend analysis mode,trigger evaluation period,number to output on>
H-17-10 ISO/IEC 16022 Symbol Quality Output 3
Serial Cmd: < K802, output on symbol contrast,symbol contrast threshold,output on print
growth,print growth threshold,output on axial non-uniformity,axial non-uniformity
threshold,output on UEC,UEC threshold>
H-17-11 ISO/IEC 15415 Symbol Quality Output 3
Serial Cmd: < K872 , output on overall grade, overall grade threshold, symbol contrast,
symbol contrast threshold, modulation, modulation threshold, reflectance
margin, reflectance margin threshold, fixed pattern damage, fixed pattern
damage threshold, axial non-uniformity, axial non-uniformity threshold, grid
non-uniformity, grid non-uniformity threshold, unused ECC, unused ECC
threshold>
