Appendices
I-14
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
I-7-4 Decode
Definition: Decode is calculated and graded for each scan and provided for the
overall grade calculation in accordance with the ISO 15416 specifica-
tion. The parameter grade and value provided for output is an average
value for each measured scan over the entire symbol.
When enabled, the Decode is attached to the symbol output data as a
value.
Serial Cmd: <K726, aperture, overall, edge determination, decode, contrast, mini-
mum reflectance, minimum edge contrast, modulation, defects, decod-
ability, quiet zone>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-7-5 Contrast
Definition: Contrast measurements assume 8-bit, 0 to 255 grey correlate to 0 to
100% reflectance. Contrast is calculated and graded for each scan and
provided for the overall grade calculation in accordance with the ISO
15416 specification. The parameter grade and value provided for out-
put is an average value for each measured scan over the entire symbol.
When enabled, the Contrast is attached to the symbol output data as a
value.
Serial Cmd: <K726, aperture, overall, edge determination, decode, contrast, mini-
mum reflectance, minimum edge contrast, modulation, defects, decod-
ability, quiet zone>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-7-6 Minimum Reflectance
Definition: Minimum reflectance is calculated and graded for each scan and pro-
vided for the overall grade calculation in accordance with the ISO
15416 specification. The parameter grade and value provided for out-
put is an average value for each measured scan over the entire symbol.
When enabled, the Minimum Reflectance is attached to the symbol out-
put data as a value.
Serial Cmd: <K726, aperture, overall, edge determination, decode, contrast, mini-
mum reflectance, minimum edge contrast, modulation, defects, decod-
ability, quiet zone>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-7-7 Minimum Edge Contrast
Definition: Contrast measurement assume 8-bit 0 to 255 grey correlate 0 to 100%
reflectance The Minimum Edge Contrast is calculated and graded for
each scan and provided for the overall grade calculation in accordance
with the ISO 15416 specification. The parameter grade and value pro-
vided for output is an average value for each measured scan over the
entire symbol.
When enabled, the Minimum Edge Contrast is attached to the symbol
output data as a value.
Serial Cmd: <K726, aperture, overall, edge determination, decode, contrast, mini-
mum reflectance, minimum edge contrast, modulation, defects, decod-
ability, quiet zone>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
