Omron MicroHAWK V320-F User Manual

Appendices
L-6
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
L-4-6 Row Pointer
Definition: The image dimension settings can be applied as a Window of Interest or a
Region of Interest, depending on the image dimension mode selected in the
Database Mode command.
Serial Cmd:
< K255, index,exposure,gain,focal distance,pixel binning, row pointer ,column
pointer,row depth,column width,symbology,morphology operator,morphology size>
Default: All models: 0
Options: V430-F000 50C QSXGA: 0 to (1944 – row depth)
V430-F000 12M SXGA: 0 to (960 – row depth)
V430-F M03M WVGA: 0 to (480 – row depth)
L-4-7 Column Pointer
Definition: The image dimension settings can be applied as a Window of Interest or a
Region of Interest, depending on the image dimension mode selected in the
Database Mode command.
Serial Cmd:
< K255, index,exposure,gain,focal distance,pixel binning,row pointer, column
pointer
,row depth,column width,symbology,morphology operator,morphology size>
Default All models: 0
Options: V430-F000 50C QSXGA: 0 to (2592 – column width)
V430-F000 12M SXGA: 0 to (1280 – column width)
V430-F M03M WVGA: 0 to (752 – column width)
L-4-8 Row Depth
Definition: The image dimension settings can be applied as a Window of Interest or a
Region of Interest, depending on the image dimension mode selected in the
Database Mode command.
Serial Cmd:
< K255, index,exposure,gain,focal distance,pixel binning,row pointer,column pointer,
row depth ,column width,symbology,morphology operator,morphology size>
Default: V430-F000 50C QSXGA: 1944
V430-F000 12M SXGA: 960
V430-F M03M WVGA: 480
Options: V430-F000 50C QSXGA: 3 to (1944 – row pointer)
V430-F000 12M SXGA: 3 to (960 – row pointer)
V430-F M03M WVGA: 3 to (480 – row pointer)
L-4-9 Column Width
Definition: The image dimension settings can be applied as a Window of Interest or a
Region of Interest, depending on the image dimension mode selected in the
Database Mode command.
Serial Cmd:
< K255, index,exposure,gain,focal distance,pixel binning,row pointer,column pointer,
row depth,
column width ,symbology,morphology operator,morphology size>
Default V430-F000 50C QSXGA: 2592
V430-F000 12M SXGA: 1280
V430-F M03M WVGA: 752
Options: V430-F000 50C QSXGA: 8 to (2592 – column pointer)
V430-F000 12M SXGA: 8 to (1280 – column pointer)
V430-F M03M WVGA: 8 to (752 – column pointer)
