L-7
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
L-4 Configuration Database Status
L
L-4-10 Symbology
When Symbology is disabled, the database uses the current Symbology setup to determine active
symbologies.
All symbologies except Pharmacode are enabled while this database index is being used.
If enabled, Data Matrix will be active for this database index.
• Important: The ECC level must be configured using the Data Matrix command <K479>. If no ECC level has been con-
figured, the reader will not decode Data Matrix symbols.
If enabled, QR Code will be active for this database index.
If enabled, Code 128 will be active for this database index.
If enabled, Code 39 will be active for this database index.
If enabled, Codabar will be active for this database index.
If enabled, Code 93 will be active for this database index.
If enabled, Interleaved 2 of 5 will be active for this database index.
L-4-10 Symbology
Definition:
This field allows the user to configure the database to enable specific symbologies
for selected database indexes. Symbology-specific parameters must be
configured with the appropriate symbology command.
For example, if fixed length Code 128 is required, it must first be set up with
the Code 128 command:
<K474>
.
To select a particular symbology, add the number value associated with that
symbology.
Examples:
If Data Matrix and Code 39 are required, the paramater would be: 2 + 16 =
18
.
If I 2/5, BC412, and DataBar Limited are required, the parameter would be:
128 + 2048 + 16384 = 18560.
Serial Cmd:
<
K255,
index,exposure,gain,focal distance,pixel binning,row pointer,column pointer,
row depth,column width,
symbology
,morphology operator,morphology size>
Default: Disabled
Disabled
Any Symbology (Add 1)
Data Matrix (Add 2)
QR Code (Add 4)
Code 128 (Add 8)
Code 39 (Add 16)
Codabar (Add 32)
Code 93 (Add 64)
Interleaved 2 of 5 (Add 128)
To Next Page
