4 Setup
4-6
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
The Enhance dropdown menu at the bottom of the Acquire editor allows you to select the method for
processing captured images.
Grow Dark increases the dark cell size of a symbol. It is useful for increasing the dark cell size of a
dark-on-light Data Matrix symbol.
Shrink Dark increases the light cell size of a symbol. It is useful for increasing the light cell size of a
light-on-dark Data Matrix symbol.
Connect Dark removes minor light defects of dark cells.
Separate Dark removes minor dark defects of light cells.
The Operator Size dropdown menu determines the size of the area or “pixel neighborhood” in which the
enhance operation is being performed.
Small corresponds to an area of 3 pixels by 3 pixels.
Medium corresponds to an area of 5 pixels by 5 pixels.
Large corresponds to an area of 7 pixels by 7 pixels.
4-2-3 Enhance
Grow Dark
Shrink Dark
Connect Dark
Separate Dark
4-2-4 Operator Size
Small
Medium
Large
