3 Select Device - Reset.
You can also right-click the icon and select Reset
from the pop up menu.
4 The following dialog box is displayed.
• If you click the Yes
Button:
The following dialog box is displayed.
Restart the device.
Clear the tag data link settings and restart
the device.
NOTE : The Controller will not be restarted.
Select the Initialize tag data link configuration, and then emulate cycling power Option,
and then click the OK Button.
9 Tag Data Link Functions
9-64
NX-series EtherNet/IP Unit User's Manual (W627)
