Start Connection Button:
Starts all connections for which the device is the originator
.
Stop Connection Button:
Stops all connections for which the device is the originator.
9-2-13
Clearing the Device Parameters
You can clear the tag data link settings (or return them to their factory settings) that are saved in the
registered EtherNet/IP device.
The following shows how to clear tag data link parameters. For details on how to connect to the net-
work from the Network Configurator, refer to 9-2-8 Connecting the Network Configurator to the Net-
work
on page 9-48.
Precautions for Correct Use
• Use the Network Configurator version 3.58 or higher to perform the following procedure to
clear the tag data link settings.
• If you perform the following procedure from the Network Configurator version 3.57 or lower,
the tag data link settings are not cleared. Refer to Additional Information in this section for the
procedure to clear the tag data link settings from the Network Configurator version 3.57 or
lower
.
1 Connect the Network Configurator to the network.
2 Select the icon of the device from which you want to clear the device parameters.
In the following example, two nodes are selected: 192.168.250.1 and 192.168.250.2. To select
multiple nodes, press and hold the Shift
Key while you select additional icons.
9 Tag Data Link Functions
9-63
NX-series EtherNet/IP Unit User's Manual (W627)
9-2 Setting Tag Data Links
9
9-2-13 Clearing the Device Parameters
