2-1
Specifications
This section provides general specifications, performance specifications, and function specifications of
the NX-series EtherNet/IP Unit.
2-1-1
General Specifications
The general specifications of the NX-series EtherNet/IP Unit are given below.
Item Specification
Enclosure Mounted in a panel
Grounding method Ground to less than 100 Ω.
Dimensions: Height × Depth × Width 100 × 120 × 39 (mm)
Weight 350 g max.
Power consumption 8.1 W max.
Operating environment Ambient operating tem-
perature
0 to 55°C
Ambient operating hu-
midity
10% to 95% (with no icing or condensation)
Atmosphere Must be free from corrosive gases.
Ambient storage tem-
perature
-25 to 70°C (with no icing or condensation)
Altitude 2,000 m max.
Pollution degree 2 or less: Meets IEC 61010-2-201.
Noise immunity 2 kV on power supply line (Conforms to IEC 61000-4-4.)
Overvoltage category Category II: Meets IEC 61010-2-201.
EMC immunity level Zone B
Vibration resistance Conforms to IEC 60068-2-6.
5 to 8.4 Hz with 3.5-mm amplitude,
8.4 to 150 Hz, acceleration of 9.8 m/s
2
100 min each in X, Y
, and Z directions (10 sweeps of 10
min each = 100 min total)
Gravity acceleration is assumed to be G=9.8m/s
2
.
Shock resistance
Conforms to IEC 60068-2-27, 147 m/s
2
, 3 times in X, Y
,
and Z directions.
Gravity acceleration is assumed to be G=9.8m/s
2
.
Mounting method Mount to DIN Track
Mounting direction One direction (upright)
Applicable standards Refer to the OMRON website (http://
www.ia.omron.com/) or consult your OMRON represen-
tative for the applicable standards.
2 Specifications and Application Procedures
2-2
NX-series EtherNet/IP Unit User's Manual (W627)
